Vascular Doppler Devices
Vascular Doppler uses high-frequency sound waves to measure the amount of blood flow through your arteries and veins, usually those that supply blood to your arms and legs. Vascular flow studies can help detect abnormal blood flow within a blood vessel.
Bidirectional Doppler
A bidirectional Doppler uses the Doppler shift technique to distinguish blood flow in both
positive and negative directions, i.e., away from the probe or towards the probe. Using phaser technology, these devices simultaneously separate forward and backward flow signals by comparing phases and pass them on through two separate channels. These devices help in the qualitative assessment of blood flow using parameters such as the shape of the curve and the direction of flow. The use of a surgical probe along with a bidirectional Doppler provides increased access to the region being assessed.
Kodys Bidirectional Dopplers
Kody Medical Electronics, a leading manufacturer of diabetic foot care and wound care equipment, offers a wide range of hand held Vascular Dopplers to cater to different needs.
ES-100VX Minidop, Bidop ES100V3, Smartdop 45, Bidop7, Hadeco Smartdop XT 6 Port, Hadeco Smartdop XT 14 Port, and Smartdop 30EX are popular bidirectional Doppler devices used widely in surgical practice. They find applications in neurosurgery, cardiovascular surgery, oral surgery, urology and nephrology, plastic surgery, and orthopaedic surgery.
Kody Medicals offers a wide range of surgical probes of different diameters that can be used at 10 and 20 MHz frequencies. These probes are used along with the Doppler devices to enhance performance and achieve excellent surgical outcomes.
Features and Applications
The Minidop ES-100VX has multifrequency compatibility and can be used with 10 and 20 MHz. The choice of probe depends on the sensitivity required and the location to be accessed. This probe plays a significant role in tracing the location of the carotid artery during pituitary tumour decompression and in patency assessment before and after the clipping of aneurysms.
Bidop 100V3 is similar to ES-100V3, with a colour display, a bigger speaker, and an inbuilt battery. It displays numerical parameters such as maximum velocity (cm/s), average velocity (cm/s), diastolic velocity (cm/s), systolic to the diastolic ratio (SD), etc. that are of value while observing blood flow. Smartdop 45 is again very similar to Bidop 100V3 and ES-100V3 with the same features with a thermal printer in addition.
All these Doppler devices find wide application in aneurysm clipping, pituitary tumour decompression, tumourectomy, etc. in neurosurgery; bypass surgery, detection of peripheral blood flow after surgery, etc. in cardiovascular surgery; lip and cleft palate surgery; varicocele and AV shunt in urology; perforator flap assessment and transplantation in plastic surgery; and determination of PAD and spinal stenosis in orthopaedic surgery.
The right choice of Doppler device from the wide range combined with the appropriate surgical probe of the right dimension contributes to the accuracy of various surgical procedures, yielding excellent results.
S. No | Parameters | Minidop ES100VX | Bidop ES100V3 | Bidop 7 | Smartdop 45 |
1 | 8 MHz Bidirectional Probe | Yes | Yes | Yes | Yes |
2 | 10 MHz VRP, NRP, CRP and LRP Intraop Doppler Probes for Plastic, Neuro, Cardiac and Laparascopic Applications | Yes | Yes | Yes | Yes |
3 | 20 MHz NRP Intraop Doppler Probe for Neuro Applications | Yes | Yes | Yes | Yes |
4 | 2 MHz Probe | Yes | Yes | Yes | Yes |
5 | Precordial Doppler Probe for Air Emboli Monitoring | Nil | Yes | Nil | Nil |
6 | 9V Alkaline Battery | Yes | Yes | Yes | Yes |
7 | Waveform with Display of Numerical parameters such as Velocity (cm/s), Volume (ml/min), Pulsatility Index, Resistance Parameter, Systolic to Diastolic Ratio | Nil | Yes | Yes | Yes |
8 | LCD Display | Nil | Yes | Nil | Yes |
9 | Color Display | Nil | Nil | Yes | Nil |
10 | Inbuilt Battery | Nil | Nil | Yes | Yes |
11 | Inbuilt Printer | Nil | Nil | Nil | Yes |
